IVF & Fertility Centre Design in Pakistan | ACCO
An IVF and fertility centre is one of the most technically exacting facilities in modern medicine — embryos surviving outside the body for days require cleanroom-grade air, precise temperature, low VOC finishes, and vibration-isolated incubators. The tiniest environmental fluctuation can end a treatment cycle. Building a modern IVF centre design Pakistan project requires ISO 5 cleanroom expertise, cryogenic storage engineering, and complete privacy and dignity for patients.
At Ahmed Construction Company (ACCO), we design and build IVF centres, embryology labs, and reproductive medicine wings across Pakistan.
—
👶 What Is an IVF & Fertility Centre?
An IVF (In Vitro Fertilisation) and fertility centre offers comprehensive assisted reproductive technology (ART) services — fertility diagnosis, ovulation induction, IUI, IVF/ICSI, embryo transfer, cryo-preservation, and andrology.
Types of Reproductive Facilities
- Basic Fertility Clinic: Consultation, IUI, no embryology.
- IVF Centre: Full ART incl. IVF/ICSI, embryology lab, cryo-storage.
- Advanced Reproductive Institute: IVF + PGT-A + donor programs.
- Fertility Wing in Gyne Hospital: Integrated with obstetrics.
—
🏥 Core Departments
- Fertility consultation OPD.
- Ultrasound room (transvaginal, follicular monitoring).
- Hormone / endocrinology lab.
- Andrology lab (semen analysis, preparation).
- Sperm collection room (private, comfortable).
- Oocyte retrieval OT (ISO 7).
- Embryology laboratory (ISO 5 core).
- Embryo transfer room.
- Cryo-storage room (LN2 tanks).
- Recovery bays.
- Counselling and consent rooms.
- Pharmacy (fertility drugs).
- Administration (strict confidentiality).
—
📏 Space Programme for a Mid-Size IVF Centre
| Department | Area (m²) |
|---|---|
| Fertility OPD & Consultation | 200–300 |
| Ultrasound Rooms | 80–120 |
| Hormone / Endocrinology Lab | 60–90 |
| Andrology Lab & Sperm Collection | 60–90 |
| Oocyte Retrieval OT (ISO 7) | 50–70 |
| Embryology Lab (ISO 5 + ISO 7 anteroom) | 80–120 |
| Embryo Transfer Room | 40–60 |
| Cryo-Storage Room | 40–60 |
| Recovery (6–8 bays) | 100–150 |
| Counselling Rooms | 60–90 |
| Pharmacy | 30–50 |
| Administration | 80–120 |
| Support & Circulation (30%) | 350–500 |
| Total | 1,230–1,820 m² |
—
🧬 Embryology Lab — The ISO 5 Cleanroom Core
The embryology lab is where oocytes and embryos live for 3–5 days between retrieval and transfer. It is a Class 100 (ISO 5) cleanroom nested inside a Class 10,000 (ISO 7) anteroom.
Embryology Lab Design Parameters
- Room size: 30–45 m² (core) + 20–35 m² anteroom.
- ISO 5 at working surface level under laminar flow hood.
- ISO 7 in general lab space.
- HEPA H14 + activated carbon (VOC removal) filtration.
- Temperature: 22–24 °C ±1 °C.
- Humidity: 40–50% ±5%.
- Air changes: 25–40 ACH.
- Positive pressure (+15 Pa).
- Zero VOC finishes (low-emission paint, floor, ceiling).
- No aromatic materials, no fragrances, no VOC cleaning chemicals.
- Vibration-isolated slab for micromanipulators.
- Anti-static flooring.
- UPS-backed critical branch for incubators (min 30 min).
- CO2 gas supply (medical-grade) with reserve.
- N2 supply for cryo work.
- Sound isolation < 40 dB(A).
- Minimal windows (UV-filtered).
- Interlocked doors.
- Environmental monitoring 24/7.
—
🔒 Cryo-Storage Room
- Room size: 15–25 m².
- Liquid nitrogen storage tanks.
- Adequate ventilation (LN2 boils → O2 displacement risk).
- Oxygen depletion alarm.
- Emergency exhaust ventilation.
- LN2 supply piping from external tank.
- Barcode / RFID inventory tracking.
- Backup power for monitoring systems.
- Dual-witness protocol infrastructure.
—
🔬 Oocyte Retrieval OT & Embryo Transfer Room
- Oocyte retrieval OT: 50–70 m², ISO 7, sedation, transvaginal ultrasound guidance.
- Direct hatch to embryology lab (pass-through window under sterile conditions).
- Recovery bay adjacent.
- Embryo transfer room: 40–60 m², calm ambience, ultrasound guided.
- Direct hatch from embryology lab for embryo transport.
—
💨 HVAC Summary
| Zone | Temp | Humidity | ACH | Filter |
|---|---|---|---|---|
| Embryology Lab (core) | 22–24 °C ±1 | 40–50% ±5 | 25–40 | HEPA H14 + carbon |
| Anteroom (ISO 7) | 22–24 °C | 40–50% | 15–20 | HEPA H13 |
| Oocyte Retrieval OT | 20–22 °C | 40–55% | 20–25 | HEPA H13 |
| Embryo Transfer | 22–24 °C | 40–55% | 15–20 | HEPA H13 |
| Cryo-Storage | 18–22 °C | Ambient | 15–20 exhaust | MERV 13 + O2 alarm |
| Andrology Lab | 22–24 °C | 40–50% | 10–15 | HEPA H13 |
—
💰 Cost Breakdown for a Mid-Size IVF Centre (2026)
- Civil & structure: PKR 4–6 crore.
- MEP (specialised HVAC): PKR 8–14 crore.
- Cleanroom fit-out: PKR 6–10 crore.
- Interior & finishes: PKR 5–8 crore.
- Embryology equipment (incubators, microscopes, micromanipulators): PKR 12–25 crore.
- Cryo-storage & LN2 system: PKR 2–4 crore.
- Andrology equipment: PKR 1–2 crore.
- Ultrasound & imaging: PKR 3–5 crore.
- Hormone lab: PKR 2–4 crore.
- FF&E: PKR 2–4 crore.
- IT & digital records: PKR 2–3 crore.
- Consultancy & approvals: PKR 2–3 crore.
- Contingency: PKR 4–6 crore.
- Total (excl. land): PKR 53–94 crore
—
📋 Regulatory & Ethical Framework
- PHC / SHCC / KP HCC hospital licensing.
- Pakistan Society of Reproductive Medicine (PSRM) guidelines.
- ISO 5 / ISO 7 cleanroom validation.
- Ethical review board approval for donor and PGD services.
- Cryo-storage safety compliance.
- PMDC registration.
- DRAP pharmacy license.
- Confidentiality and data protection.
See: Hospital Regulatory Approvals.
—
⚖️ IVF Centre vs Fertility Wing in Gyne Hospital
| Aspect | Standalone IVF Centre | Fertility Wing in Gyne Hospital |
|---|---|---|
| Focus | ART-only, dedicated | Integrated with obstetrics |
| Embryology Lab | Dedicated ISO 5 | Same standard |
| Marketing Position | Specialty brand | Continuum of care |
| Investment | PKR 55–95 crore | PKR 40–75 crore add-on |
| Best For | ART-focused business | Existing maternity practice |
—
🏨 ACCO’s IVF Centre Approach
- ISO 5 embryology cleanroom with VOC-free finishes.
- Vibration-isolated micromanipulator benches.
- UPS + redundant CO2 for incubator safety.
- Cryo-storage with O2 depletion alarm and emergency exhaust.
- Confidential, private patient flow with dignity-first design.
- Turnkey coordination with embryology equipment vendors.
Related: Gynaecology & Obstetrics Hospital Design · Hospital HVAC & Cleanroom Standards.
—
❓ Frequently Asked Questions
How much does an IVF centre cost to build in Pakistan?
A mid-size IVF centre with ISO 5 embryology lab, OT, cryo-storage, and full andrology typically costs PKR 53–94 crore including equipment.
How long does construction take?
12–18 months from feasibility to soft launch. Cleanroom validation adds 4–6 weeks at the end.
What is ISO 5 and why does it matter?
ISO 5 (Class 100) permits max 3,520 particles ≥0.5 μm per m³ — the cleanroom class required at the working surface where embryos are handled.
Why must the embryology lab be VOC-free?
Volatile organic compounds from paint, adhesives, and cleaning chemicals are toxic to embryos and reduce fertilisation and implantation rates.
Can I include the IVF centre as a wing in my maternity hospital?
Yes. Many successful IVF programs are integrated wings of gynae hospitals. ACCO designs both models.
—
