10 Marla House Construction in Pakistan 2027: Your Complete Design, Cost & Planning Guide

10 Marla House Construction in Pakistan 2027: Your Complete Design, Cost & Planning Guide

10 Marla House Construction in Pakistan 2027: Your Complete Design, Cost & Planning Guide

By , CEO, Ahmed Construction Company (ACCO) · Updated · Reviewed by ACCO architects and engineers

Since 1998Design and construction in Lahore
Based in Gulberg-IIIHead office in Lahore
Architects + EngineersArchitecture, structure and MEP in-house
Free DrawingsOn award of construction

Quick Answer

Plan your 10 Marla house construction in Pakistan with ACCO. Get design, cost, and timeline insights for 2027. Book a free consultation today. Ahmed Construction Company (ACCO), based in Gulberg-III Lahore since 1998, provides house construction in Lahore with design drawings free on award of construction.

A 10 Marla house is the most popular family home size in Lahore and other Punjab cities: large enough for four or five bedrooms, yet manageable in cost and upkeep. Building one well takes more than a good contractor; it needs a design that fits the family, drawings that the site can follow and a budget based on a clear scope. This guide covers 10 Marla house construction in Pakistan for 2027, from layout and approvals to indicative costs, stages and timelines.

10 Marla House Construction at a Glance

Plot sizeAbout 2,250 sq ft; common dimensions are 35 x 65 ft or 40 x 56 ft depending on the society
Typical covered areaAbout 3,500 to 4,000 sq ft for a double-storey house
Typical accommodation4 to 5 bedrooms with attached baths, drawing, dining, lounge, kitchen and parking for 2 cars
Indicative cost (Lahore)Grey structure about PKR 2,800 to 3,500 per sq ft; complete standard house about PKR 6,700 to 8,800 per sq ft (2026-27 working range)
Typical durationAbout 12 to 18 months for a complete house after approvals

Costs are indicative and change with material prices and specification. A firm price needs approved drawings and an itemised BOQ.

Planning a 10 Marla Layout

On a 10 Marla plot every square foot counts, so the layout must be efficient. A typical plan places the drawing room, dining, kitchen and one bedroom on the ground floor, with three bedrooms and a family lounge on the first floor. The roof can take a servant room, laundry and water tanks.

  • Place the stair centrally to keep corridors short
  • Use the front setback for parking and the rear for light and ventilation
  • Give each bedroom an attached bath, with stacked wet areas to simplify plumbing
  • Plan air-conditioner positions, solar panels and tanks from the start

For ideas on style and elevation, see our modern house design guide.

Approvals and Drawings

Each society, whether DHA, Bahria Town, LDA or a private scheme, has its own bylaws for setbacks, coverage, height and basements. Submission drawings must comply before construction can start. Beyond approval drawings, the site needs working drawings: architectural details, structural drawings designed to the Building Code of Pakistan, and electrical and plumbing layouts. Building from approval drawings alone is a common cause of mistakes and disputes.

Indicative Budget for a 10 Marla House

ScopeIndicative rate per sq ftBudget for about 3,750 sq ft
Grey structurePKR 2,800 to 3,500About PKR 1.05 to 1.3 crore
Complete standard housePKR 6,700 to 8,800About PKR 2.5 to 3.3 crore

A basement, imported fittings, extensive glazing or stone cladding will raise these figures. For a detailed breakdown, read our grey structure cost guide and house construction cost guide.

Construction Stages

Foundations

Excavation, PCC, footings, plinth beams, damp-proofing and termite treatment.

Structure

Columns, beams, slabs and brickwork with embedded conduits and pipes.

Roof and plaster

Waterproofing, insulation and internal and external plaster.

Finishing

Flooring, woodwork, paint, kitchen, baths, electrical fixtures and elevation.

Where Quality Matters Most

Steel and concrete

Use certified Grade 60 steel, correct cover and tested concrete. These cannot be upgraded later.

Waterproofing

Roofs, baths and basements need proper waterproofing; leaks are expensive to trace and repair.

Services

Good-quality pipes, wiring and earthing behind the plaster save years of repairs.

Managing the Project

Agree a written contract with a defined scope, specification, schedule and stage payments linked to inspected work. Keep a record of variations and approve them in writing before they are carried out. Overseas owners should ask for regular photo and video updates and a single point of contact. Our guide for overseas Pakistanis building in Lahore covers remote management in detail.

Frequently Asked Questions

How much does a 10 Marla house cost to build in Lahore?

As an indicative 2026-27 range, about PKR 1.05 to 1.3 crore for grey structure and about PKR 2.5 to 3.3 crore for a complete standard house of around 3,750 sq ft. The final cost depends on design and specification.

How long does it take to build a 10 Marla house?

Usually around 12 to 18 months for a complete house after approvals, longer with a basement or high-end finishes.

How many bedrooms can a 10 Marla house have?

Most double-storey 10 Marla houses have four or five bedrooms with attached baths.

Do you build outside Lahore?

ACCO is based in Lahore and also takes projects in other cities in Pakistan, subject to project size and scope.

Conclusion

A well-built 10 Marla house starts with an efficient layout, complete drawings and an honest budget, followed by disciplined site supervision. ACCO offers house construction in Lahore from design through grey structure and finishing, with free architectural drawings when the construction work is awarded to us.
