Build Your Dream Home: The Complete 2026-27 Grey Structure Cost Guide

Build Your Dream Home: The Complete 2026-27 Grey Structure Cost Guide

Build Your Dream Home: The Complete 2026-27 Grey Structure Cost Guide

By , CEO, Ahmed Construction Company (ACCO) · Updated · Reviewed by ACCO architects and engineers

Since 1998Design and construction in Lahore
Based in Gulberg-IIIHead office in Lahore
Architects + EngineersArchitecture, structure and MEP in-house
Free DrawingsOn award of construction

Quick Answer

Planning to build in 2026-27? Get expert insights on grey structure construction in Pakistan, cost factors, and timelines. Build with ACCO's 25+ years of trust. Ahmed Construction Company (ACCO), based in Gulberg-III Lahore since 1998, provides house construction in Lahore with design drawings free on award of construction.

Many homeowners spend heavily on tiles, lighting and fittings while accepting a weaker structure to save money. That is the wrong way round. The grey structure carries your home for its whole life and cannot be upgraded later without major demolition. This guide explains grey structure construction in Pakistan for 2026-27: what the package should include, the specifications that matter, how the work is sequenced and how to budget for it sensibly.

Grey Structure Construction at a Glance

DefinitionThe structural shell of a building: foundations, frame, walls, roof and plaster, with services embedded
Indicative rateAbout PKR 2,800 to 3,500 per sq ft of covered area in Lahore (2026-27 working range)
Critical specificationsSteel grade and cover, concrete strength, brick quality, curing and waterproofing
Typical durationAround four to six months for a standard double-storey house
Detailed costsSee the grey structure cost guide

What a Proper Grey Structure Package Includes

Foundations

Excavation, PCC, footings or raft, plinth beams, backfilling and anti-termite treatment.

RCC frame

Columns, beams, slabs and stairs to approved structural drawings, using certified Grade 60 steel.

Masonry

External, internal and boundary walls in good-quality bricks or blocks with correct mortar ratios.

Embedded services

Electrical conduits, plumbing, drainage and gas lines fixed before plaster.

Roof protection

Waterproofing and insulation over the top slab, essential in Pakistan’s climate.

Plaster

Internal and external plaster to line and level, ready for finishing.

Usually excluded: flooring, doors, windows, paint, sanitary and electrical fittings, kitchen, wardrobes, ceilings and elevation cladding.

Specifications That Decide Quality

ItemWhat to check
SteelGrade 60 deformed bars from a reputable mill, with mill certificates; correct bar sizes, spacing and cover
ConcreteSpecified mix or strength, clean aggregates, proper vibration, cube tests and at least seven days of curing
BricksWell-burnt, uniform bricks soaked before use; correct mortar ratio and joint thickness
Damp-proofingDPC at plinth level to stop rising damp
RoofProper slopes to drains, waterproofing membrane or treatment, and insulation

How Grey Structure Work Is Sequenced

Setting out

Marking the building on site from approved drawings and checking levels.

Foundations

Excavation, PCC, footings and plinth beams, with steel inspected before each pour.

Frame and walls

Columns, slabs and masonry floor by floor, with conduits and pipes fixed as work proceeds.

Roof and plaster

Waterproofing, insulation and plaster before handover to finishing.

Budgeting for Grey Structure

Grey structure is usually somewhat less than half of the cost of a complete house with standard finishes. The rate per square foot depends on the specification, the design’s complexity, whether there is a basement and the market prices of steel and cement at the time of construction. A with-material contract with a clear specification is easier to control than a labour-only contract where the owner buys materials. For a full house budget, see our house construction cost guide.

Red Flags in Grey Structure Quotes

  • No mention of steel brand, grade or concrete strength
  • Roof waterproofing, DPC or termite treatment missing
  • No structural drawings, only an architectural plan
  • Payments based on time rather than completed stages
  • A rate far below the market without an explanation

Frequently Asked Questions

What is included in grey structure construction?

Foundations, the RCC frame, brickwork, embedded service lines, damp-proofing, roof waterproofing and plaster. Finishing items are excluded.

What is the grey structure rate in Lahore?

ACCO’s indicative 2026-27 working range is about PKR 2,800 to 3,500 per square foot of covered area, depending on specification and site.

How long does grey structure take?

Around four to six months for a standard double-storey house without a basement.

What payment terms are usual?

A mobilisation advance followed by stage payments for foundations, each slab, masonry and plaster, released after inspection.

Conclusion

The grey structure is the one part of your home you cannot easily fix later, so specify it properly, supervise it closely and price it on a clear scope. ACCO provides grey structure construction in Lahore with engineering supervision and itemised BOQs, as part of our wider house construction services.
