Firefighting & Emergency Evacuation Systems for Commercial High-Rises in Pakistan
By Tanveer Ahmed, CEO, Ahmed Construction Company (ACCO) · Updated · Reviewed by ACCO architects and engineers
Quick Answer
Firefighting systems for high-rise buildings in Pakistan: sprinklers, risers, fire pumps, alarms, pressurised stairs and evacuation for commercial towers. Ahmed Construction Company (ACCO), based in Gulberg-III Lahore since 1998, provides MEP & firefighting services with design drawings free on award of construction.
Firefighting systems for high-rise buildings in Pakistan have become a central part of commercial design as plazas and mixed-use towers in Lahore, Karachi and Islamabad grow taller. In a tall building, fire brigade ladders cannot reach the upper floors, and occupants may need several minutes to reach the ground. The building itself must therefore detect a fire early, control it, keep escape routes free of smoke and give firefighters the water and access they need. This guide explains the main active and passive fire systems, how evacuation is planned, and what owners should require from their designers and contractors.
High-Rise Fire Safety at a Glance
| Main systems | Fire detection and alarm, automatic sprinklers, wet risers and hose reels, fire pumps and water storage, smoke control, pressurised stairs, emergency lighting and signage |
|---|---|
| Passive protection | Fire-rated compartments, protected shafts and stairs, fire doors, fire-stopping of service penetrations |
| Key references | Fire Safety Provisions of the Building Code of Pakistan (PEC); NFPA standards such as NFPA 13 (sprinklers), NFPA 14 (standpipes), NFPA 20 (fire pumps), NFPA 72 (alarms) and NFPA 101 (life safety) |
| Who checks | The approving development authority and local fire and emergency services, with requirements varying by city |
| Design service | ACCO firefighting system design as part of coordinated MEP |
Why High-Rises Need a Different Approach
A fire on the tenth floor of a plaza behaves very differently from a fire in a house. Three factors make tall buildings harder to protect:
- Limited external access. Aerial ladders reach only a certain height, so firefighting on upper floors depends on internal systems.
- Vertical spread. Smoke and fire travel through stairs, lift shafts, service ducts and gaps in façades unless these are sealed and compartmented.
- Long escape times. Hundreds of people may need to descend many floors through the same stairs that firefighters use to go up.
For these reasons, high-rise fire safety is designed as an integrated strategy from the start, not as a set of devices added at the end of construction.
Passive Fire Protection
Passive protection is built into the structure and is always working, even when power fails.
Compartmentation
Floors and walls are designed to resist fire for a defined period, dividing the building into compartments so a fire is contained where it starts.
Protected shafts and stairs
Escape stairs, lift shafts and vertical service risers are enclosed in fire-resisting construction with fire-rated doors.
Fire doors
Tested fire doors with self-closers, smoke seals and suitable hardware must stay closed in normal use; wedged-open fire doors are one of the most common failures found in Pakistani buildings.
Fire-stopping
Every pipe, duct and cable passing through a fire-rated wall or slab needs a tested fire-stop seal. Unsealed openings let smoke move between floors.
Façades
Cladding and insulation materials should have appropriate fire performance, and the gap between floor slabs and curtain walls must be sealed.
Active Fire Protection Systems
Detection and alarm
Addressable smoke and heat detectors, manual call points and sounders, ideally with voice evacuation in large buildings. See fire alarm and detection systems.
Automatic sprinklers
Designed hydraulically to NFPA 13 so a fire is controlled close to where it starts.
Wet risers and hose reels
Pipes kept charged with water, with landing valves on each floor for firefighters and hose reels for first response.
Special suppression
Clean-agent systems for server and electrical rooms where water would cause damage.
Fire Pumps and Water Storage
Sprinklers and risers only work if water arrives at the right pressure, even during a power cut. A typical high-rise fire pump installation includes:
- A dedicated fire water tank sized for the design duration
- A main electric fire pump
- A standby diesel-driven pump independent of grid power
- A small jockey pump to keep the system pressurised
- Controllers, test lines and alarms monitored by the fire panel
Very tall buildings may need pressure zones or intermediate pump stations. See our fire pump and tank design service.
Smoke Control and Stair Pressurisation
Smoke, not flame, causes most fire deaths. High-rise smoke control commonly uses:
- Stair pressurisation: fans push fresh air into escape stairs so smoke cannot enter when doors open.
- Lobby protection: ventilated or pressurised lobbies between floors and stairs.
- Smoke extraction: in basements, atriums and large retail floors.
- HVAC shutdown or smoke mode: air-conditioning systems controlled by the fire alarm so they do not spread smoke.
Emergency Evacuation Planning
Evacuation design decides how people leave the building safely.
Escape routes
At least two independent escape routes from each floor, with travel distances, stair widths and door widths sized for the occupant load.
Phased or simultaneous evacuation
Very tall buildings may evacuate the fire floor and adjacent floors first, while other floors wait, so stairs do not overload. This requires reliable compartmentation and a voice alarm.
Emergency lighting and signage
Battery-backed lighting and photoluminescent signs keep routes visible during power failure.
Firefighting lifts
Lifts with protected power supply and controls allow firefighters to reach upper floors quickly.
Assembly points and drills
Safe assembly areas away from the building, trained fire wardens and regular drills turn the design into a working plan.
Basements, Car Parks and Plant Rooms
Basements are often the highest-risk part of a commercial tower. They contain vehicles, generators, fuel, electrical switchgear and storage, and smoke has no natural way out.
- Smoke extraction with jet fans or ducted systems to clear smoke and give firefighters visibility.
- Sprinkler coverage throughout parking levels and storage areas.
- Fire-rated enclosures for generator rooms, fuel storage, transformers and switchgear.
- Protected stair access from every basement level, separated from the ground-floor lobby.
- Clear signage and lighting so drivers and pedestrians can find exits quickly.
Responsibilities of Owners and Building Managers
A well-designed system can still fail if the building is poorly managed. Owners and managers of commercial high-rises should keep up-to-date fire safety drawings, maintain a log of inspections and tests, train fire wardens on every floor, run evacuation drills, and review every tenant fit-out for its effect on sprinklers, detectors and compartments. Including these duties in tenancy agreements and service-charge budgets makes them part of normal building operation rather than an afterthought.
Ordinary Plaza vs High-Rise Fire Strategy
| Element | Low-rise plaza | Commercial high-rise |
|---|---|---|
| Detection | Conventional alarm | Addressable alarm with voice evacuation |
| Suppression | Extinguishers, hose reels | Full sprinkler coverage, wet risers |
| Water supply | Shared tank | Dedicated fire tank with electric, diesel and jockey pumps |
| Stairs | Protected stair | Two or more pressurised stairs |
| Lifts | Passenger lifts | Includes firefighting lift |
| Evacuation | Simultaneous | Phased evacuation may be used |
Integration With Building Management Systems
In a modern tower, the fire alarm panel does more than sound an alarm. Through a defined cause-and-effect matrix it can release door holders, start stair pressurisation fans, switch air-handling units to smoke mode, return lifts to the ground floor, start fire pumps and alert the control room. Linking the fire system to the building management system (BMS) gives managers a single view of alarms, pump status and faults. Every one of these interfaces must be tested together before handover, because a system that works in isolation can still fail when it depends on another.
Designing, Installing and Maintaining the Systems
Fire strategy
Compartments, escape routes and systems defined with the architecture.
Detailed design
Hydraulic calculations, alarm zoning, smoke control and pump sizing.
Installation and testing
Pressure tests, flow tests, alarm cause-and-effect and pump runs witnessed before handover.
Maintenance
Scheduled inspection and testing throughout the life of the building.
ACCO designs these systems with the rest of the building services; see MEP and firefighting and high-rise building design and construction.
Common Fire Safety Failures in Pakistani Buildings
- Escape stairs used for storage or locked for security
- Fire doors removed, wedged open or replaced with ordinary doors
- Unsealed service shafts allowing smoke to spread between floors
- Fire pumps not tested, or diesel pumps without fuel
- Alarm systems disabled because of false alarms
- Tenant fit-outs that block sprinklers or alter compartments without review
Frequently Asked Questions
Are sprinklers required in high-rise buildings in Pakistan?
Requirements depend on the approving authority, building height and use, but sprinklers are generally expected in tall commercial buildings and are strongly recommended under NFPA principles.
Why do high-rises need pressurised stairs?
Pressurisation keeps smoke out of escape stairs when doors open, so occupants can evacuate and firefighters can use the stairs safely.
Why is a diesel fire pump needed?
Grid power may fail during a fire. A diesel pump runs independently, keeping sprinklers and risers supplied with water.
Can existing plazas be upgraded?
Yes. Many older buildings can add alarms, emergency lighting, fire doors, fire-stopping and, in some cases, sprinklers and risers. A fire safety survey identifies what is practical.
How often should fire systems be tested?
Alarms, pumps and sprinklers need routine inspection and testing on schedules set by the relevant standards and the system supplier, with records kept by building management.
Does ACCO design firefighting systems?
Yes. ACCO designs and installs fire detection, sprinkler, riser and pump systems as part of coordinated MEP design for plazas, hospitals and high-rises.
Conclusion
Fire safety in a commercial high-rise depends on passive protection, active systems and a clear evacuation plan working together. Designing these from the first concept, testing them properly at handover and maintaining them throughout the building’s life protect occupants, property and the owner’s investment. For healthcare buildings, see our related guide to hospital fire safety design.
